L-Sealer Shrink Wrapping Systems
Complete Semi-Automatic L-Sealer and Heat Tunnel Systems for Consistent, Professional Shrink Packs
These industrial systems combine motor-driven L-sealing and a matched shrink tunnel on one compact chassis. The operator positions the product in centre-folded film, the L-bar seals and cuts the pack, and the conveyor transfers it directly through the tunnel for a tight, consistent finish. Two sizes cover products from compact retail packs to larger multipacks.
Complete System
L-sealer and matched heat tunnel on one chassis
Two Size Options
58/44 and 80/65 sealing formats
No Compressed Air
Motor-driven sealing for straightforward installation
Why Choose an Integrated L-Sealer and Heat Tunnel?
One Complete Shrink-Wrapping Process — Sealing and shrinking happen in a single, continuous workflow, removing the need to match separate machines or manually transfer packs between them.
Compact, Practical Layout — Mounting the L-sealer and tunnel on one mobile chassis reduces floor-space requirements and keeps operating controls, film and product flow together.
Consistent Pack Presentation — Adjustable sealing, conveyor speed and tunnel temperature help produce clean seals and a controlled shrink finish across changing products and film gauges.
Flexible for Varied Product Runs — Adjustable product support, conveyor height and operating parameters suit short and medium production runs with regular size changes.
See the Complete Seal-and-Shrink Process
See product positioning, L-sealing, tunnel shrinking and finished-pack outfeed within one semi-automatic workflow.
Key Features of the L-Sealer Combination Range
Motor-driven semi-automatic sealing, controlled tunnel shrinking and two working sizes for varied product dimensions.
- Integrated L-sealer and heat tunnel supplied as a matched, single-chassis system
- Motor-driven sealing bar with no compressed-air requirement
- Automatic timed cycle or push-button free mode
- Adjustable sealing power for compatible film thicknesses
- Digital control of heat, time and conveyor speed
- Up to 10–15 packs per minute, depending on product, film and operator
- Maximum product height of 150mm
- Adjustable tunnel conveyor height and running time
- Safety sensor stops the sealing cycle if an obstruction is detected
- Mobile construction for positioning and maintenance access
Technical Specifications
Current working specifications. Final requirements will be confirmed against the selected machine configuration.
Ideal for Retail Products, Printed Materials, Components, Multipacks and Contract Packing
These combination systems suit operations needing flexible semi-automatic shrink wrapping, regular product changeovers and a consistent presentation finish.
